| Brand Name: | Qtenboard |
| Price: | NA |
| Payment Terms: | T/T |
| Product Certification | CEFCCRoHSREACHCCC and more |
|---|---|
| Factory Certification | ISO 9001ISO 4001ISO 27001ISO 45001 and more |
| Flexible Production | Customized samples within 72 hours, MOQ=1 |
| Quality Inspection | AI visual inspection with 99% yield rate |
| Parameter | 23.8" Model | 32" Model |
|---|---|---|
| Resolution | 1920 × 1080 | 1920 × 1080 |
| Display Scale | 16:9 | 16:9 |
| Brightness | 250 cd/㎡ | 280 cd/㎡ |
| Contrast | 1200:1 | 1200:1 |
| Color | 8bits-true (16.7M) | 8bits-true (16.7M) |
| Maximum Viewing Angle | 178° | 178° |
| Parameter | 23.8" Model | 32" Model |
|---|---|---|
| Remote Control | Support voice remote control (optional) | Support voice remote control (optional) |
| USB 2.0 OTG | ×1 | ×1 |
| Type-C | ×1 | ×1 |
| AUX | ×1 | ×1 |
| HDMI | ×1 (optional) | ×1 (optional) |
| 4G SIM Slot | ×1 | ×1 |
| Front Camera | 800W | 1300W |
| MIC | Dual array | Dual array |
| Gross Weight | 18KG | 21KG |
| Parameter | 23.8" Model | 32" Model |
|---|---|---|
| CPU | MTK MT6769 (12nm) 2×Cortex-A75 up to 2.0Ghz + 6×Cortex-A55 up to 1.8Ghz | |
| Version | 13.0 | |
| RAM | 4GB/8G | 4G/8G |
| ROM | 128G/256G/512G | 128G/128G |
| WLAN Function | 2.4/5GHz WIFI, support WiFi hotspot | |
| Bluetooth | BT4.2 | |
| Parameter | 23.8" Model | 32" Model |
|---|---|---|
| Battery Material | 18650 ternary lithium | |
| Charge/Discharge Cycles | 1000 times - capacity retention ≥85% | |
| Battery Specifications | 11.1V 10000mAh 111Wh | 14.8V 7800mAh 115W |
| Charging Time | 3H | |
| Battery Life | 4.5H | |
| Charging Method | PD-Type C charging | |
| Accessory | 23.8" Model | 32" Model |
|---|---|---|
| Data Cable | Type-C data cable (Optional) | Type-C data cable (Optional) |
| Remote Control | Quantity: 1 (Optional) | Quantity: 1 (Optional) |
| Power Adapter | 19V/3.8A | PD-87W, Type-C adapter |
| Capacitive Stylus | Quantity: 1 piece (Optional) | Quantity: 1 piece (Optional) |
| Mobile Cart | Quantity: 1 set | Quantity: 1 set |
|
